BIOS1 24V

Control units for 1 gearmotor 24 Vdc

BIOS1 24V Control unit for sliding gates, without transformer.

Main characteristics:
• Control unit with managing of a transmitter through the display.
• Extractable memory and terminal boards.
• Electronic torque adjustment.
• Learning up to 1000 transmitters.
• Functions selection through display.
• Self–learning of strokes.
• Differentiable slowing downs during opening and closing phase.
• Adjustable obstacle detection.
• Self-diagnosis of safety devices.
• Led for inputs status.
• Radio receiver module.

Inputs: open button, close button, step–by–step button, pedestrian button, stop button, 2 photocells, safety edge, open and close limit switch.
Outputs: Integrated flashing circuit 230 Vac, courtesy light and power supply accessories (24 Vdc).

Dim. (mm) W x D x H = 90 x 125 x 45 SK

Transformer TCT44 for BIOS1 24V
